Description
ADJ Sweeper Beam Quad LED, RGBW Lighting Fixture with Wired Digital Communication Network – 8 Watt
The ADJ Sweeper Beam Quad LED, RGBW Lighting Fixture with Wired Digital Communication Network – 8 Watt is with quick sweeping narrow beams combined with an 8-Zone RGBW LED chase. It offers LED pulse and strobe effects. This fixture features eight 8W bright, quad LEDs with a narrow beam angle of 3.4°, 4 DMX channel modes, and a 4-channel LED DMX menu.
The Sweeper Beam LED Fixture can be controlled via its own built-in programs, a DMX controller (available separately), or the easy-to-use UC3 Controller (available separately). It is designed for stages, nightclubs, and mobile entertainers. This fixture can also be used in multiples.
.iframe-container{
position: relative;
width: 100%;
padding-bottom: 56.25%;
height: 0;
}
.iframe-container iframe{
position: absolute;
top:0;
left: 0;
width: 100%;
height: 100%;
}
Product Specifications:
Fixture Type: Moving Head
Light Source: 8x Color LED – 8 W
Expected Lamp Life: 50,000 Hours
Colors: Red, Green, Blue, White
Pixel Configuration: 8x Zone
Beam Angle: 3.4°
Shutter / Strobe: Electronic
Dimming: Electronic
Operating Modes: DMX, Sound-Active
Macros / Programs: Show, Sound-Active
Effects: Light Beams, Strobe
Gobos: No
Tilt Ranges: 270°
Pan/Tilt Inversion: No
Control Protocols: DMX512
DMX Channel Modes (4): 1 / 6 / 35 / 39-Channel
Display / Controls: LED / 4-Button
Remote Control: UC3 (with Optional Equipment)
Inputs/Outputs: 1 x XLR 3-Pin DMX Input, 1 x XLR 3-Pin DMX Output
AC Input Power: 100 to 240 VAC, 50/60 Hz
AC Power Connector: Input: 1x IEC, Output: 1x IEC
Fuse: 7 A
Power / Current Consumption: 81 W
Power Linking: 4 Units at 120 VAC, 7 Units at 230 VACS
Environmental
Environmental Protection: No
Mounting: Floor Base, Mounting Bracket
Exterior Color: Black
Cooling: Convection
Certifications: cETLus
Dimensions: 38.5 x 5.25 x 3″ / 977.9 x 133.35 x 76.2 mm
Product Weight: 13.8 lb.
Shipping Weight: 14 lb. / 6.4 kg
Shipping Dimensions (LxWxH):41 x 7.5 x 6“
