Description
RCF UP-1121 Power Amplifier – 120-Watt
The RCF UP-1121 Power Amplifier – 120-Watt with a single balanced line level audio input. The amplifier audio output is for low impedance loudspeakers or 100 – 70 V constant voltage line transformer loudspeakers. In addition to the connection to the main power supply, the UP 1121 features a 24 VDC input to be powered by external batteries.
Product Specifications:
Power Output: 120 W RMS
Frequency Response: 60 Hz to 15 kHz
Distortion: < 1.5%
Signal / Noise: > 80 dB
Crosstalk: > 80 dB
Line Input Sensitivity: 1 V (+2 dBu)
Line Input Impedance: 10 kOhms
Auxiliary Input Impedance: 10 kOhms
Output Voltage: 70 V (83 ohms) / 100 V (167 ohms)
Operating Voltage: 115-230 V, 50/60 Hz
Power Consumption: 120 W
Control: Master volume, Treble, Bass
Protections: Overload, short-circuit, thermal
Dimensions: 3.4 x 16.96 x 15.15″ (88 x 431 x 385 mm)
Weight: 26.45 lb (12 kg)
Package Weight: 30
Package Dimension: 20, 13, 8”
